Validation of the Geometry for Jig Assemblies Via Digitization
A global leader in the Aerospace and Defense industry
.png)
Project Scope
- Scanned the entire jig parts and assemblies.
- Measure the geometry of the jig assemblies for wings and tail nose.
- Validate the geometry of the jig assemblies using optical photogrammetry system.
Project Deliverables
- STL mesh using polygonised high density point data.
- Scanned assemblies of the wings and tail nose in IGES format.
- Coordinate points in Excel spreadsheets.
Key Tools
- Optical Photogrammetry System
- SolidWorks 2020
