Thermal Analysis of 6U VPX Plug-in unit

Case Study

A Fortune 500 company in defense sector

Case Study Image

Project Scope

  • Non-linear transient thermal analysis at PCB level.
  • Design and thermal analysis of thermal pad for 6U VPX PCBs (CPU, I/O, Backplane, and Front Panel/Connector).
  • Design and thermal analysis of outer chassis consisting of PCB and thermal pad.

Project Deliverables

  • Thermal gradient, heat flow rate and temperature contour plots are recorded at the PCB level, thermal pad and outer surface of the chassis with variation in time.

Key Tools

  • Hypermesh
  • Analysis on LS-DYNA
